This is a 2.9 inch color epaper display with high resolution 384x168 resolution, SPI interface, and the display is capable to display images with black, white and red content. Your image holds indefinitely without power – put up your image, then shut down the power. Once these e-paper modules are updated they don't require any power and can actually be disconnected entirely and the content will remain on the display indefinitely. This e-paper display GDEY029F51H is perfect for low power devices powered by solar or batteries.
We provide the E-Ink Adapter Board for you to connect the E-paper Display.
We could provide front light, touch screen and other accessories for you.
Relevant manual about this product on Library or you could go to our official website (www.good-display.com), contact us please.
* This e-ink display module DOES NOT support partial updates.
Package A | + | ||||||||
a. 2.9 inch electronic paper screen JD79661 384x168 color e-ink display GDEY029F51H * 1pc | b. FPC Connector * 1pc | ||||||||
|
|||||||||
Package B | + | + | |||||||
a. 2.9 inch electronic paper screen JD79661 384x168 color e-ink display GDEY029F51H * 1pc | b. FPC Connector * 1pc | c.Epaper HAT Connection Adapter Board for E Ink Display, DESPI-C02* 1pc | |||||||
|
|||||||||
Package C | + | + | + | ||||||
a. 2.9 inch electronic paper screen JD79661 384x168 color e-ink display GDEY029F51H * *2pcs | b. FPC Connector * 2pcs | c.STM32 E-paper Panel Driver Board Type-C Interface Eink Development Kit, DESPI-L(C02) * 1pc | d. USB Cable * 1pc | ||||||
|
Package D | + | + | + | ||||
a. 2.9 inch electronic paper screen JD79661 384x168 color e-ink display GDEY029F51H *2pcs | b. FPC Connector * 2pcs | c. ESP32 Arduino Platform E-paper Panel Driver Board Type-C Interface Eink Development Kit, ESP32-L(C02) * 1pc | d. USB Cable * 1pc |
PART NUMBER |
GDEY029F51H |
||
SIZE |
2.9 inch |
STORAGE TEMP. | -25℃~60℃ |
TYPE |
Dot Matrix |
CONNECTOR | 24 Pin FPC |
IC |
JD79667 |
MAX GRAYSCALE | 2 |
RESOLUTION |
384x168 |
COLOR | Black, White, Yellow, Red |
OUTLINE SIZE(mm) |
79x35.57x1.2 |
INTERFACE | SPI |
ACTIVE SIZE(mm) |
67.58x29.57 |
FULL REFRESH(s) | 25 |
PIXEL PITCH(mm) |
0.176x0.176 |
POWER CONSUMPTION OF THE REFRESH(mW) | 9.9 |
OPERATING TEMP. |
0℃~40℃ |
STANDBY POWER CONSUMPTION (mW) | 0.003 |
● Versatile. Use in portrait or landscape format.
● Bistable. (Will continue to display with no power source)
● I2C Signal Master Interface to read external temperature sensor
● Black, white and red. Compared with monochrome electronic paper display, it is more beautiful
● Development platform available STM32 / Arduino / ESP8266 / ESP32
☆ DRAWING
☆ MATCHED DEVELOPMENT KIT
● DESPI-C02 (E-ink Display HAT)
● DESPI-L(C02) (STM32 Platform/Universal)
● DEArduino-L(C02) (Arduino Platform)
● ESP32-L(C02) (WiFi / Bluetooth)
● GDEY029F51H Specification
● Picture Production and Bitmap Convert for GDEY029F51H
● GDEY029F51H STM32 Sample Code
● GDEY029F51H ESP32 Sample Code
