Any questions, just feel free to contact me, my email is: clara@good-display.com
There are plenty in stock, welcome to your order!
1)5'' 640x480 TFT LCD Panel *1pc
2)DC12V power input AD Board with VGA,Video interface *1pc
3)Cable with VGA terminal *1pc
4)Cable with Keypad terminal *1pc
5)Cable with Power input & Video input terminal *1pc
6)5'' 4 wire resistive touch screen *1pc
7)Driver board for touch *1pc
8)Mini rainbow cable for connecting touchscreen and driver board *1pc
9)RS232 port cable for connecting driver board and PC(1.8m) *1pc
| Part Number | GDN-D567AT-GTI050NA-08C |
| Size | 5.0''(4:3) |
| Resolution | 640*480 |
| Brightness | 250cd/m2 |
| Working Voltage | DC12V(Typ.) (Min.9V, Max.15V) |
| Viewing Angle(U/D/L/R) | 50/70/70/70 |
| Signal input | VGA,VIDEO |
| Outside dimension of lcd panel(mm) | 117.65(W)*88.43(H)*5.7(D) |
| Active Area of lcd panel(mm) | 101.57(W)*76.18(H) |
| Structural dimension of PCBA(mm) | 105.0(W)*50.0(H)*7.8(D) |
| Backlight | LED |
| Operating temperature | -10C~+60C |
| Storage temperature | -20C~+70C |
http://www.e-paper-display.com/products_detail/productId=92.html
1)We accept credit cards, T/T bank transfer,paypal, Moneybookers and debit cards.
2)We cannot arrange shipments on weekend or public holidays.
3)Your orders will be shipped out within 48 working hours on receipt of cleared payment. (Excludes Saturdays & Sundays)
4) We'll add a tracking number after sending the item so that you can track your parcel.
5)Please be advised that the international delivery time highly depends on your local customs and post services policy.
6)Customs fees and import duties for exports are your responsibility.
We cannot predict or prepay these fees. We will charge you for any duties or customs fees erroneously charged to us.
1)We'll leave POSITIVE FEEDBACK on receipt of cleared payment.
2)If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us.
3)Once any problems occured, please contact us first. We'll try our best to work things out.
|
Part Number |
Size |
Resolution |
Features |
| GDS058SZY35KV |
5.8 inch |
800 x 300 |
bar TFT display |
| GDS088JZA31QE |
8.8 inch |
1280 x 320 |
bar TFT display |
| GHT210HDP33 |
21 inch |
1920 x 132 |
bar TFT display |
| GD35TTD |
3.5 inch |
320 x 240 |
TFT LCD panel |
| GDS050WV43 |
5.0 inch |
800 x 480 |
TFT LCD panel |
| GDN-D43AT-GDS050WV43 |
5.0 inch |
800 x 480 |
TFT LCD panel |
|
5.6 inch |
640 x480 |
TFT LCD panel |
|
| GTI056TN52-U |
5.6 inch |
640 x 480 |
TFT LCD panel |
| GTI070TN90 |
7.0 inch |
800 x 480 |
TFT LCD panel |
| GTIEJ080NA-05B |
8.0 inch |
800 x 600 |
TFT LCD panel |
| GTT24P138 |
2.4 inch |
480 x 234 |
TFT LCD module |
| GD24TWD-GTT24P138 |
2.4 inch |
480 x 234 |
TFT LCD module |
| GDN-D43AT-GTT035KDH03 |
3.5 inch |
320 x 240 |
TFT LCD module |
| GDN43M03-GTT035KDH03 |
3.5 inch |
320 x 240 |
TFT LCD module |
| GD40M05-GTT035KDH03 |
3.5 inch |
320 x 240 |
TFT LCD module |
| GD40M05-GKD035G6-54NT-V1 |
3.5 inch |
320 x 240 |
TFT LCD module |
| GDN-D43AT-GDS043WQ26H |
4.3 inch |
480 x 272 |
TFT LCD module |
|
5.0 inch |
640 x 480 |
TFT LCD module |
|
| GDN-D567AT-GTI050NA-08C-RM |
5.0 inch |
640 x 480 |
TFT LCD module |
| GDN-D567AT-GTI056TN52-U |
5.6 inch |
640 x 480 |
TFT LCD module |
| GDN-D567AT-GTI056TN52 |
5.6 inch |
640 x 480 |
TFT LCD module |
| GD567M03-GTI070TN90 |
7.0 inch |
800 x 480 |
TFT LCD module |
| GD70M6M-GTH070NA-13B-27H |
7.0 inch |
1024 x 600 |
TFT LCD module |
| GD70MLXD-GTI070TN83 |
7.0 inch |
800 x 480 |
TFT LCD module |
| GDN-HD156AU-GTI070NA |
7.0 inch |
1024 x 600 |
TFT LCD module |
| GDN-D102AT-GTI080NA |
8.0 inch |
800 x 600 |
TFT LCD module |
| GDN-HD156AU-GTI080IA |
8.0 inch |
1024 x 768 |
TFT LCD module |
| GDN-D102AT-GTT104SDH01 |
10.4 inch |
800 x 480 |
TFT LCD module |
Please feel free to contact us for any questions, on trademanager, or send message to me. It's our pleasure to serve you! We appreciate your business!!
