GDO0066B is the graphic OLED display module made of 64x48 individual blue OLED pixels,diagonal is only 0.66 inch.The controller ic SSD1306, communicates via 8080 4-bit/8-bit parallel and I2C/4-wire serial interface,thanks to controller's built-in voltage generation,only a single 2.8V power supply is needed. Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.The fpc is the soldering type,no need connector.Just solder the FPC on your PCB directly.

Part Number | GDO0066B |
Outline Dimension | 18.46(W)x18.10(H)x1.45(T)mm |
Visual Area | 15.42x12.06mm |
Active Area | 13.42(W)x10.06(H)mm |
Display Format | 64x48 Dots |
Interface | I2C |
Display Type | OLED |
Appearance | White on Black |
Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
Operating Temperature | -40℃~70℃ |
Storage Temperature | -40℃~80℃ |
Power Supply | 2.8V |
